1. Material: Stainless Steel 304

2. Surface finishing: fine-polished, which makes the pipe surface performs better on corrosion resistance

3. Assembling feature: pipes connected by innovative inserting & turning

4. Usage: drenching body and rinsing faces /eyes can be operated separately or simultaneously

5. Shower & eye wash switch: two-piece ball valve

6. Shower head: spinning-formed with curled rim, diameter 250 mm

7. Pipe diameter: 38 mm

8. Nominal pressure: 1.0 Mpa

9. Working pressure: 0.2~0.4 Mpa

10. Testing pressure: 1.5 Mpa

11. Temperature requirement on working environment: 0℃~40℃

12. Flow rate of body shower: ≥76 L/min

13. Flow rate of eye/face wash: ≥11.4 L/min

14. Eyewash bowl features: 300 mm in diameter, vertical bowl-wall design, allows better water collecting and anti-splashing

15. Dust cover: integrated with the spray head ( not connected by chain ),and easily removed by water flow

16. Spray head feature: patented design, each spray head equips with one water-flow control valve

17. Inlet thread: Rp 1",female

18. Outlet thread: Rp 1" , female

19. Inlet height ( from above the floor ): 1201 mm

20. Outlet height ( from above the floor ): 86 mm

21. Distance between spray heads: 170 mm

22. Water pattern coverage: at the height of 1520 mm above floor, the water pattern covers a circular area of at least 510 mm in diameter

23. Notes: the inlet part and outlet part are customizable;shutoff valve and filter are proposed to be equipped on the water-supply end;stainless steel- made foot treadle is optional as eye wash switch
