1. Material: SS304

2. Surface treatment: fine polishing + high-brightness epoxy resin coating

3. Installation features: adopts "Yun-style" pipe connection method, which can be quickly assembled and disassembled

4. Function: shower + eye wash + automatic emptying by foot pedal

5. Suitable areas: low-cold areas in the north

6. Switch ball valve: two-piece quick-opening ball valve + special three-way ball valve

7. Shower nozzle: spinning curling process design, diameter 250mm

8. Pipe diameter: 48mm

9. Eye wash basin: 300mm Straight edge design, collects water and prevents splashing

10. Dust cover: integrated design of the main body, not easy to lose

11. Features of eyewash nozzle: patented design, with dual flow regulating valve

12. Water inlet size: 1" British internal thread

13. Drain size: 1" British external thread

14. Water inlet height: 110mm

15. Drain height: 50mm

16. Eyewash nozzle spacing: 170mm

17. The inlet and drain sizes can be customized according to user needs. It is recommended to set up maintenance emergency valves and filters at the water inlet.

18. This eyewash is a fully automatic emptying eyewash. Operation method:

① Stand on the foot pedal of the eyewash, push the push plate, and pull the pull rod down 90", and the eyewash will automatically discharge water.

② After use, the push plate, dust cover and pull rod are reset.

③ When the person leaves the foot pedal, the water outlet valve is automatically closed. At the same time, the accumulated water in the entire eyewash system pipeline can be directly emptied to prevent freezing and ensure the normal use of the eyewash in freezing weather. There is no need to perform the secondary emptying valve action, which is convenient and quick.
