1. Inner material: SSS304

2. Outer material: ABS removable shell

3. Installation features: It has the function of heat preservation and antifreeze, equipped with self-limiting temperature electric heating belt and temperature control system

4. Function: spray + eye wash (can be used at the same time or separately)

5. Explosion-proof level ExdbIIBT4/Ex dbIIBT6/ExdbIICT4 /ExdbIICT6 (can be customized according to customer requirements)

6. Protection level: IP65/IP66 (can be customized)

7. Switch ball valve: conventional two-piece ball valve (three-piece ball valve can be customized)

8. Eye wash basin: 300mm straight edge design, water collection and concentration

9. Nominal pressure: 1.0Mpa

10. Working pressure: 0.2~0.4Mpa

11. Test pressure: 1.5Mpa

12. Spray water flow: > 76L/MIN

13. Face/eye wash water flow: > 11.4 L/MIN

14. Water inlet size: 1-1/4" flange

15. Drain size: 1" flange

16. Water inlet height: 170mm

17. Drain height: 100mm

18 Product features:

① This product is suitable for use in areas below 0℃. When the water temperature is below 0℃, the eyewash tube will automatically turn on the heating function to eliminate the possibility of damage caused by low temperature.

② A flow alarm valve is installed at the water inlet, and an explosion-proof sound and light alarm is installed on the top of the product. Once a user starts the eyewash, the sound and light alarm lights will start working, which can not only inform others that someone is operating here, but also achieve the purpose of requesting assistance.

③ An explosion-proof intelligent lighting device is installed at the nozzle port of the eyewash, and a light-controlled switch device is used. While effectively saving electricity, it is convenient for the injured to use it at night.

④ This product is equipped with polyurethane thermal insulation material for thermal insulation protection, which avoids the change of water temperature in the eyewash pipe affected by the change of external environment temperature, and more effectively ensures that the injured person gets the appropriate eyewash water temperature.

⑤ The water source of the eyewash adopts a centralized explosion-proof heating system for centralized heat release. The explosion-proof heating system has the functions of preventing dry burning, preventing leakage (automatically cutting off the power supply when leakage occurs) and reliable temperature control, which can effectively increase the water temperature of the eyewash by 15℃ and not higher than 38℃.

⑥ The eyewash has an automatic emptying device, and the accumulated water in the eyewash system can be completely emptied in 15 seconds, which more effectively improves the antifreeze function of the eyewash system and ensures that the eyewash water is clean and hygienic.
